K5 pro
Place of Origin： China
Essential details
- Warranty:
1 year
- Customized support:
ODM
- Place of Origin:
Tianjin, China
- Model Number:
K5 Pro
- Horizontal:
±0.25m+1ppm
- Vertical:
±0.50m+1ppm
- Size:
17.5 x 17.5 x 8.3 cm
- Weight:
1.33 kg (2 batteries included)
- User interface:
Five Indicator lights
- Galileo:
giove-a and giove-b, E1, E5A, E5B
- GPS:
L1C/A, L1C, L2C, L2E
- BDS:
B1, B2, B3
Essential details
- Warranty:
1 year
- Customized support:
ODM
- Place of Origin:
Tianjin, China
- Model Number:
K5 Pro
- Horizontal:
±0.25m+1ppm
- Vertical:
±0.50m+1ppm
- Size:
17.5 x 17.5 x 8.3 cm
- Weight:
1.33 kg (2 batteries included)
- User interface:
Five Indicator lights
- Galileo:
giove-a and giove-b, E1, E5A, E5B
- GPS:
L1C/A, L1C, L2C, L2E
- BDS:
B1, B2, B3
GNSS characteristics | 965 GNSS channels | GPS: L1C/A, L1C, L2C, L2E; |
BDS: B1, B2, B3; |
GLONASS: L1C/A, L1P, L2C/A, L2P; SBAS: L1C/A; |
Galileo: giove-a and giove-b, E1, E5A, E5B; |
SBAS: L1C/A, L5 |
Initialization | time <10s, reliability >99.99% |
Output data formats | NMEA 0183, PJK plane coordinates, Binary code, Trimble GSOF |
Positioning | Code differential GNSS positioning | Horizontal: ±0.25m+1ppm |
Accuracy | Vertical: ±0.50m+1ppm |
|
| SBAS positioning accuracy: typically<5m 3DRMS |
| Static | Horizontal: ±2.5mm+0.5ppm |
|
| Vertical: ±5mm+0.5ppm |
| Real-time kinematic (RTK) | Horizontal: ±8mm+1ppm |
| Vertical: ±15mm+1ppm |
| Network RTK | Horizontal: ±8mm+0.5ppm |
| Vertical: ±15mm+0.5ppm |
| RTK initialization time | 2~8s |
Physical characteristics | Size | 17.5 x 17.5 x 8.3 cm |
Weight | 1.33 kg (2 batteries included) |
User interface | Five Indicator lights |
Two buttons |
Linux System |
Tilt Compensation | Without Tilt (default configuration) |
Tilt Sensor with 30° working range (optional) |
IMU Sensor with 60° working range(optional) |
