X6
Place of Origin： China
Essential details
- Warranty:
1 year
- Place of Origin:
China
- Brand Name:
CHC
- Model Number:
X6
Essential details
- Warranty:
1 year
- Place of Origin:
China
- Brand Name:
CHC
- Model Number:
X6
GNSS Performance X6/i73 |
Channels | 624 channels |
GPS | L1, L2, L5 |
GLONASS | L1, L2 |
Galileo | E1, E5a, E5b |
BeiDou | B1, B2, B3 |
SBAS | L1 |
QZSS | L1, L2, L5 |
GNSS Accuracies |
Real time Vertical: 15 mm+ 1 ppm RMS kinematics (RTK | Horizontal: 8 mm+ 1 ppm RMS |
Vertical: 15 mm+ 1 ppm RMS |
Initialization time: < 10 s |
Initialization reliability: > 99.9% |
Post -processing kinematics (PPK) | Horizontal: 3 mm + 1 ppm RMS |
Vertical: 5 mm + 1 ppm RMS |
Post - processing static | Horizontal: 2.5 mm+ 0.5 ppm RMS |
Vertical: 5 mm+ 0.5 ppm RMS |
Code differential | Horizontal: 0.4 m RMS |
Vertical: 0.8 m RMS |
Autonomous | Horizontal: 1 m RMS |
Vertical: 1.5 m RMS |
Positioning rate | 1 Hz, 5 Hz and 10 Hz |
Time to first fix (3) | Cold start: < 45 s |
Time to first fix (3) Hot start: < 30 s |
Signal re-acquisition: < 2 s |
| Additional horizontal pole-tilt uncertainty typically less than 10 mm + 0.7 mm/°tilt |
RTK tilt - compensation |
Hardware |
Size (L x W x H) | 119 mmx 119 mmx 85 mm |
Weight | 0.73 kg |
Ingress protection | IP67 waterproof and dustproof, protected from temporary immersion to depth 1m |
Tilt sensor | Calibration - free IMU for pole -tilt compensation. Immune to magnetic disturbances. |
Shock | Survive a 2-meter pole drop |
Ports | 1 x USB Type-C port (data download, charging, firmware update) |
1 x UHFantenna port (TNC female) |
Operating time on RTK Rover 12 h internal battery | RTK Rover 12 h internal battery (4) Static: up to 15 h |
