GNSS configuration | Number of channels: 660 |
BDS: B1, B21I, B3I, B1C. B2a .GPS: L1, L2. L5 |
|
GLONASS: L1. L2 |
GALILIEO: E1. E5a, E5b |
QZSS: L1. L2. L5 |
SBAS: support |
output format | ASCII: NMEA-0183,binary code ASCII: NMEA-0183, binary code |
Positioning output frequency | 1Hz~20Hz |
static data format | GNS, Rinex dual format static data |
Differential format | CMR，RTCM2.X, RTCM3.0, RTCM3.2 |
network mode | VRS, FKP, MAC; support NTRIP protocol |
System Configuration | operating system | Linux operating system |
Start Time | 3 seconds |
data storage | Built-in 8GB ROM, support automatic cycle storage of static data |
Accuracy and reliability[1] | RTK positioning accuracy | Plane: ±(8+1x10-6D) mm (D is the distance between the measured points) |
Elevation: ±(15+1x10-6D) mm (D is the distance between the measured points) |
Static positioning accuracy | Plane: soil (2.5+0.5x10-6D) mm (D is the distance between the measured points) |
Elevation: soil (5+0.5x10-6D) mm (D is the distance between the measured points) |
DGPS positioning accuracy | Plane Accuracy: +0.25m+1ppm; Elevation Accuracy: +0.50m+ 1ppm |
SBAS positioning accuracy | 0.5m |
Initialization time | <10 seconds |
Initialization reliability | > 99.99% |
I/O ports | 5-pin interface, USB Type C interface, SMA interface, Nano SIM card slot |
Built-in eSIM | Including 3 years of Internet access fee, you can connect to the Internet without inserting a card |
Built-in 4G network communication | TDD-LTE. FDD-LTE. WCDMA. EDGE. GPRS. GSM |
WiFi communication | 802.11 a/b/g/n access point and client mode for WiFi hotspot service |
Bluetooth communication | Bluetooth4.2/2.1+EDR,2.4GHz |
communication unit | Built-in radio | Built-in transceiver integrated radio: |
Power: 0.5W/1W/2W adjustable |
Frequency: 410MHz~470MHz |
Protocol: HI-TARGET, TRIMTALK450S, TRIMMARKM, TRANSEOT, SoutH |
Number of channels: 116 (16 of which are configurable) |
Plug-in radio | Full protocol plug-in radio |
Power: 10W\30W adjustable, frequency band: 403~473MHz. |
Protocol: HI-TARGET, TRIMTALK450S, TRIMMARKI, TRANSEOT, SOUTH, CHC, SATEL Transmission rate: 19.2kbps/9.6kbps adjustable |
Channels: 116 (16 of which are configurable) |
sensor | electronic bubble | Achieve smart centering |
Inclination measurement | Built-in high-precision inertial navigation, automatic attitude compensation, no correction, anti-magnetic interference,
point-to-point measurement, accuracy of 3 cm. |
User Interface | button | two buttons |
display | 0.94-inch 240*120 high-resolution OLED high-definition color display |
LED indicator light | satellite light, signal light |
Functional application | Advanced Features | OTG function, NFC IGRS, WebUI interaction, U disk firmware upgrade, network relay |
Smart application | Intelligent base station, intelligent voice, function self-test, fast battery charging, AR measurement, AR stakeout |
Remote Service | Message push, online upgrade, remote control |
cloud service | Device management, location services, collaborative work, data analysis |
physical properties | Host battery | Built-in high-capacity lithium battery 6800mAh/7.4V, network mobile station working time 10 hours[2] |
Support fast charge | Support USB PD3.0 super fast charging, charging time is s3.5 hours. Support power bank charging. |
External power supply | 6~28V wide voltage DC design, 5 core interface |
size | φ156mmx77mm |
weight | Less than or equal to 1.25kg (including battery) |
Power consumption | 4.2W |
Material | The shell is made of magnesium alloy material |
Environmental characteristics | Dustproof and waterproof | IP68 |
Anti-drop | Anti-2 meters high measuring rod natural drop |
Relative humidity | 100% non-condensing |
Operating temperature | -30°C~+70°C |
storage temperature | -40°C~+80°C |
