G970IIPRO
Place of Origin： China
Essential details
- Place of Origin:
Tianjin, China
- Brand Name:
Unistrong
- Model Number:
Unistrong
Essential details
- Place of Origin:
Tianjin, China
- Brand Name:
Unistrong
- Model Number:
Unistrong
Technical parameter |
|
|
| Channels | 800 |
GNSS |
| BDS: B1, B2, B3 |
| Signals | GPS: L1CA, L1P. L1C, L2P, L2C, L5 |
|
| GLOASS: G1,G2, P1, P2 |
|
| GALILEO: E1BC, E5a. E5b |
|
| QZSS: L1CA. L2C. L5, L1C |
|
| SBAS: L1CA, L5; |
|
| L-Band |
| Static | H: 2.5 mm±1ppm , V: 5 mm±1ppm |
Accuracy | RTK | H: 8 mm±1ppm, V:15 mm±1ppm |
| DGNSS | <0.5m |
| ATLAS | 8cm |
| Initialization Time | 8s |
|
|
|
|
| Initialization Reliable | 99.90% |
| Operating System | Linux |
| Merrory | 8GB, support expanable MisroSD |
| Wifi | 802.11 b/g/n |
| Bluetooth | V2.1+EDR/V4.1Dual,Class2 |
| E-Bubble | support |
| Tilt Survey | IMU Tilt Survey 60°,Fusion Positioning/400Hz refresh rate |
| Battery Capacity | 7. 2v, 24. 5wh(2 Batteries Standard) |
Power | Life Timer | Static: 15h Rover: 12h |
| Extemal Power Source | 9-18V DC, Overvoltage Protection |
| Operating Temperature | -30℃+ 65℃ |
Environmental | Storage Temperature | -40℃ . + 80℃ |
| IP Dearee | IP67 |
| Dimensions | 156DX76H |
Mechanical | weight | 1.2kg |
| Power / Data Connector | 1 TNC radio antenna . 1 5 PIN( power + RS232 ) -7PIN ( USB+RS232） |
| Keypad | 1 power button |
| Status Indications | 4LED indicator |
